Haulotte
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| Gross Power | 37.6 hp |
|---|---|
| Fuel Type | Diesel |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 79 in |
| Overall Length | 22 in |
| Overall Width | 89 in |
| Turning Radius | 183 in |
| Overall Height - mast lowered | 83 in |
Performance
| Operating Weight | 14,330 lb |
|---|---|
| Max Speed | 3.8 mph |
| Tire Size | 14x17.5 |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Tire Fill/Type | foam filled |
| Fuel Capacity | 14.6 gal |
Platform
| Max Platform Height | 530 in |
|---|---|
| Max Platform Weight Capacity | 507 lb |
| Platform Inner Length | 71 in |
| Platform Inner Width | 32 in |
| Max Working Height | 608 in |
| Max Horizontal Reach | 333 in |
| Lift Time | 45.0 s |
| Platform Rotation | 180 ° |
