Haulotte

HA33 JE

Aerial Lift

Max Platform Height
385 in
Overall Length
215 in
Overall Width
54 in
All aerial lifts
Haulotte HA33 JE Aerial Lift
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

25 data points

Engine

Engine specifications
System Voltage48 V
Battery Amp Hours345

Dimensions

Dimensions specifications
Ground Clearance6 in
Wheelbase62 in
Overall Length215 in
Overall Width54 in
Overall Height83 in
Transport Length191 in
Gradeability25.0 %
Track Width103 in
Turning Radius - Outside85 in
Tilt alarm3 °
Turntable rotation355 °

Performance

Performance specifications
Operating Weight13,109 lb
Max Speed2.8 mph
Tire Size6.00x12
Hydraulic System Fluid Capacity8.0 gal

Platform

Platform specifications
Max Platform Height385 in
Max Platform Weight Capacity500 lb
Platform Inner Length37 in
Platform Inner Width32 in
Max Working Height457 in
Max Horizontal Reach257 in
Platform Rotation170 °
Jib Range of Motion - Vertical136 °
