Hbxg
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 57,100 lb |
|---|
Engine
| Engine Model | CQNTA855-C280 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 217.3 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,450 rpm |
| Max Torque | 738 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 134 in |
| Length of Track on Ground | 126 in |
| Length w/ Blade | 300 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.3 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 89 in |
| Standard Shoe Size | 36 in |
Standard Blade
| Width | 151 in |
|---|---|
| Height | 50 in |
| Capacity | 8.31 yd³ |
