Komatsu
D65PX-17
Crawler Dozer
27 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 88,185 lb |
|---|
Engine
| Engine Model | CQNTA855-C400 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 329.9 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,200 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 156 in |
| Length of Track on Ground | 130 in |
| Length w/ Blade | 319 in |
Transmission
| Max Speed - Forward | 7.4 mph |
|---|---|
| Max Speed - Reverse | 9.2 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 15 psi |
|---|---|
| Track Gauge | 88 in |
| Standard Shoe Size | 22 in |
Standard Blade
| Width | 165 in |
|---|---|
| Height | 70 in |
| Capacity | 17.09 yd³ |
