Hbxg
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 26,456 lb |
|---|
Engine
| Engine Model | D6114 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 108.7 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 420 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 113 in |
| Length of Track on Ground | 88 in |
| Length w/ Blade | 169 in |
Transmission
| Max Speed - Forward | 5.0 mph |
|---|---|
| Max Speed - Reverse | 6.2 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 71 in |
| Standard Shoe Size | 18 in |
Standard Blade
| Width | 133 in |
|---|---|
| Height | 38 in |
