Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 39,242 lb |
|---|
Engine
| Engine Model | C6121 |
|---|---|
| Displacement | 641 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 162.3 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 583 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 102 in |
| Length w/ Blade | 206 in |
Transmission
| Max Speed - Forward | 7.1 mph |
|---|---|
| Max Speed - Reverse | 8.7 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Standard Shoe Size | 20 in |
Standard Blade
| Width | 131 in |
|---|---|
| Height | 46 in |
