Hitachi

CP210

Pneumatic Roller

Max Speed
15.0 mph
Gross Power
90.0 hp
Overall Length
17 in
Overall Width
90 in
All pneumatic rollers
Hitachi CP210 Pneumatic Roller
1 / 5
Image 1 of 5
Image: directindustry.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Max Speed15.0 mph
Fuel Capacity30.4 gal
Water Spray Tank Fluid Capacity1,056.6 gal

Engine

Engine specifications
Engine ModelBB-4BG1T
Displacement264 in³
Power Measured @2,150 rpm
Gross Power90.0 hp
Number of Cylinders4

Weights

Weights specifications
Operating Weight - standard28,484 lb
Operating Weight - max ballast37,302 lb
Average Weight per Wheel - Max Ballast5,329 lb
Average Weight per Wheel - Standard4,070 lb

Dimensions

Dimensions specifications
Ground Clearance12 in
Wheelbase152 in
Overall Length17 in
Overall Width90 in
Height - Top of ROPS/FOPS122 in

Tires & Wheels

Tires & Wheels specifications
Number of Tires - Rear4
Number of Tires - Front3
Wheel Track/Tire Overlap2 in
Standard Tire Size14/70-20-12PR (OR)
