Hitachi
Komatsu
JW30-2
Pneumatic Roller
17 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Max Speed | 15.6 mph |
|---|---|
| Fuel Capacity | 30.4 gal |
| Water Spray Tank Fluid Capacity | 977.4 gal |
Engine
| Engine Model | BB-4BG1T |
|---|---|
| Displacement | 264 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 108.0 hp |
| Number of Cylinders | 4 |
Weights
| Operating Weight - standard | 28,925 lb |
|---|---|
| Operating Weight - max ballast | 8,157 lb |
| Average Weight per Wheel - Max Ballast | 5,298 lb |
| Average Weight per Wheel - Standard | 4,132 lb |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 152 in |
| Overall Length | 17 in |
| Overall Width | 90 in |
| Height - Top of ROPS/FOPS | 110 in |
Tires & Wheels
| Number of Tires - Rear | 4 |
|---|---|
| Number of Tires - Front | 3 |
| Wheel Track/Tire Overlap | 2 in |
| Standard Tire Size | 14/70-20-12PR (OR) |
