Hitachi
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Fuel Capacity | 145.0 gal |
|---|---|
| Tire Size | Michelin 18.00R25 E4 |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 18.5 gal |
| Hydraulic System Fluid Capacity | 29.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | N14-C400 |
|---|---|
| Displacement | 855 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 400.0 hp |
| Net Power | 384.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged/Aftercooled |
| Torque Measured @ | — |
| Rated Engine Speed | 29 rpm |
Weights
| Empty Weight | 52,450 lb |
|---|---|
| Loaded Weight | 125,467 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 50.0 % |
| Weight Distribution Rear - empty | 50.0 % |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 144 in |
| Overall Length | 317 in |
| Overall Width | 148 in |
| Overall Height | 143 in |
| Dump Height | 305 in |
| Dump Ground Clearance | 19 in |
Transmission
| Max Speed | 37.1 mph |
|---|---|
| Transmission Type | Allison CLBT 754. Automatic planetary type transmission with built in retarder and 2nd gear start |
| Number of Gears - Forward | 5 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 63,993.0 gal |
|---|
Dump
| Dump Angle | 55 ° |
|---|---|
| Raise Time | 12.0 s |
| Lower Time | 12.0 s |
| Load Capacity - heaped | 27.49 yd³ |
| Load Capacity - Struck | 19.10 yd³ |
