Hitachi
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Fuel Capacity | 317.1 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 129.5 gal/min |
Engine
| Engine Model | KTTA19-C |
|---|---|
| Displacement | 1,153 in³ |
| Gross Power | 630.3 hp |
| Aspiration | Turbocharger |
| Engine Make | Cummins |
Dimensions
| Ground Clearance | 42 in |
|---|---|
| Height - Top of Cab | 179 in |
| Length of Track on Ground | 632 in |
| Tail Swing Radius | 187 in |
| Width to Outside of Tracks | 181 in |
Undercarriage
| Ground Pressure | 103 psi |
|---|---|
| Max Travel Speed | 2.3 mph |
Boom/Stick Excavator Option 1
| Max Digging Depth | 366 in |
|---|---|
| Max Reach Along Ground | 592 in |
| Max Loading Height | 357 in |
| Max Vertical Wall Digging Depth | 269 in |
| Max Cutting Height | 538 in |
| Shipping Length of Unit | 632 in |
| Shipping Height of Unit | 179 in |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
