PC650-1
Mini Excavator
20 specifications
1 / 5
Image 1 of 5
Specifications
60 data points
Operating Specifications
| Fuel Capacity | 370.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 356.7 gal |
| Operating Voltage | 24 V |
| Engine Oil Capacity | 18.5 gal |
| Cooling System Fluid Capacity | 29.9 gal |
| Swing Speed | 6 rpm |
Engine
| Engine Model | QSK23 |
|---|---|
| Displacement | 1,412 in³ |
| Power Measured @ | 1,650 rpm |
| Gross Power | 760.0 hp |
| Net Power | 721.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Dimensions
| Height - Top of Cab | 214 in |
|---|---|
| Length of Track on Ground | 198 in |
| Upper Structure Ground Clearance | 71 in |
| Length of Tracks | 252 in |
| Height of Tracks | 62 in |
Undercarriage
| Track Gauge | 154 in |
|---|---|
| Max Travel Speed | 2.2 mph |
| Number of Upper Rollers | 3 |
| Loading Shovel Operating Weight | 244,713 lb |
| Loading Shovel Shoe Width | 28 in |
| Loading Shovel Ground Pressure | 20 psi |
| Number of Lower Rollers | 8 |
| Backhoe Shoe Width 1 | 28 in |
| Backhoe Operating Weight - Shoe 1 | 238,100 lb |
| Backhoe Ground Pressure - Shoe 1 | 20 psi |
| Number of Track Shoes per Side | 52 |
| Tail Swing Radius | 192 in |
| Backhoe Shoe Width 2 | 35 in |
| Backhoe Ground Pressure - Shoe 2 | 16 psi |
| Backhoe Operating Weight - Shoe 2 | 242,500 lb |
Bucket
| Reference Bucket Capacity | 7.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 8.59 yd³ |
| Minimum Bucket Capacity | 7.80 yd³ |
Loading Shovel
| Max Dig Depth | 206 in |
|---|---|
| Max Dig Reach | 451 in |
| Max Cutting Height | 487 in |
| Max Dump Height | 344 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 313 in |
|---|---|
| Max Cutting Height | 485 in |
| Max Dump Height | 317 in |
| Max Reach on Ground | 527 in |
| Max Vertical Wall Dig Depth | 200 in |
Backhoe Boom / Stick 2
| Max Dig Depth | 369 in |
|---|---|
| Max Cutting Height | 531 in |
| Max Dump Height | 352 in |
| Max Reach on Ground | 592 in |
| Max Vertical Wall Dig Depth | 300 in |
Backhoe Boom / Stick 3
| Max Dig Depth | 410 in |
|---|---|
| Max Cutting Height | 552 in |
| Max Dump Height | 372 in |
| Max Reach on Ground | 633 in |
| Max Vertical Wall Dig Depth | 350 in |
Backhoe Boom / Stick 4
| Max Dig Depth | 450 in |
|---|---|
| Max Cutting Height | 568 in |
| Max Dump Height | 408 in |
| Max Reach on Ground | 673 in |
| Max Vertical Wall Dig Depth | 408 in |
