PC1250LC-7
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Fuel Capacity | 277.4 gal |
|---|---|
| Hydraulic System Fluid Capacity | 369.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 175 A |
| Swing Speed | 6 rpm |
Engine
| Engine Model | QSX 15 |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 509.0 hp |
| Net Power | 489.0 hp |
Dimensions
| Height - Top of Cab | 157 in |
|---|---|
| Length of Track on Ground | 203 in |
| Upper Structure Ground Clearance | 62 in |
| Length of Tracks | 251 in |
Undercarriage
| Track Gauge | 138 in |
|---|---|
| Max Travel Speed | 3.0 mph |
| Number of Upper Rollers | 3 |
| Loading Shovel Operating Weight | 188,275 lb |
| Loading Shovel Shoe Width | 24 in |
| Loading Shovel Ground Pressure | 20 psi |
| Number of Lower Rollers | 9 |
| Backhoe Shoe Width 1 | 24 in |
| Backhoe Operating Weight - Shoe 1 | 194,227 lb |
| Backhoe Ground Pressure - Shoe 1 | 19 psi |
| Tail Swing Radius | 163 in |
| Backhoe Shoe Width 2 | 30 in |
| Backhoe Ground Pressure - Shoe 2 | 15 psi |
| Backhoe Operating Weight - Shoe 2 | 196,652 lb |
| Backhoe Shoe Width 3 | 36 in |
| Backhoe Ground Pressure - Shoe 3 | 13 psi |
| Backhoe Operating Weight - Shoe 3 | 199,078 lb |
Bucket
| Maximum Bucket Capacity | 7.19 yd³ |
|---|---|
| Minimum Bucket Capacity | 4.60 yd³ |
Loading Shovel
| Max Dig Depth | 91 in |
|---|---|
| Max Dig Reach | 378 in |
| Max Cutting Height | 347 in |
| Max Dump Height | 264 in |
| Height to Top of Boom - shovel | 205 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 260 in |
|---|---|
| Max Cutting Height | 390 in |
| Max Dump Height | 269 in |
| Max Reach on Ground | 438 in |
Backhoe Boom / Stick 2
| Max Dig Depth | 276 in |
|---|---|
| Max Cutting Height | 469 in |
| Max Dump Height | 328 in |
| Max Reach on Ground | 485 in |
Backhoe Boom / Stick 3
| Max Dig Depth | 292 in |
|---|---|
| Max Cutting Height | 481 in |
| Max Dump Height | 335 in |
| Max Reach on Ground | 500 in |
Backhoe Boom / Stick 4
| Max Dig Depth | 319 in |
|---|---|
| Max Cutting Height | 493 in |
| Max Dump Height | 347 in |
| Max Reach on Ground | 524 in |
