Hitachi

EX280H-5

Excavator

Operating Weight
60,848 lb
Max Digging Depth
285 in
Net Power
167.7 hp
All excavators
Hitachi EX280H-5 Excavator
1 / 5
Image 1 of 5
Image: ebay.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight60,848 lb
Fuel Capacity100.4 gal

Engine

Engine specifications
Engine ModelH07C-TD
Power Measured @2,050 rpm
Net Power167.7 hp

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab120 in
Length of Track on Ground148 in
Tail Swing Radius117 in
Width to Outside of Tracks126 in
Removal Counterweight Clearance47 in

Undercarriage

Undercarriage specifications
Ground Pressure8 psi
Max Travel Speed2.8 mph

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth285 in
Max Reach Along Ground422 in
Max Loading Height278 in
Max Vertical Wall Digging Depth241 in
Max Cutting Height394 in
Shipping Length of Unit406 in
Shipping Height of Unit126 in

Bucket

Bucket specifications
Reference Bucket Capacity1.50 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm
