Caterpillar
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
64 data points
Operating Specifications
| Operating Weight | 36,707 lb |
|---|---|
| Fuel Capacity | 62.1 gal |
| Hydraulic Pump Flow Capacity | 21.2 gal/min |
| Hydraulic System Fluid Capacity | 60.8 gal |
| Engine Oil Capacity | 2.4 gal |
| Cooling System Fluid Capacity | 10.4 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 75 A |
| Tire Size | 10.00-20 16PR |
| Oscillating Axle Angle | 18 ° |
| Front Diff Fluid Capacity | 2.8 gal |
| Rear Diff Fluid Capacity | 3.7 gal |
| Max Steering Angle | 32 ° |
Engine
| Engine Model | 3054E |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 124.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Net Torque | 369 lb-ft |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 100 in |
| Overall Width | 8 in |
| Tail Swing Radius | 88 in |
| Overall Width - Outriggers Down | 145 in |
Transmission
| Max Travel Speed | 21.2 mph |
|---|---|
| Transmission Type | powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.20 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|---|
| Swing Torque | 29,576 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 396 in |
| Max Reach Along Ground | 352 in |
| Max Loading Height | 275 in |
| Shipping Length of Unit | 335 in |
| Shipping Height of Unit | 157 in |
| Max Vertical Wall Dig Depth | 148 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Cutting Height | 409 in |
| Max Reach Along Ground | 370 in |
| Max Loading Height | 288 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 333 in |
| Max Vertical Wall Dig Depth | 162 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 212 in |
|---|---|
| Max Cutting Height | 354 in |
| Max Reach Along Ground | 343 in |
| Max Loading Height | 236 in |
| Shipping Height of Unit | 157 in |
| Shipping Length of Unit | 328 in |
| Max Vertical Wall Dig Depth | 139 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 233 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 361 in |
| Max Loading Height | 246 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 329 in |
| Max Vertical Wall Dig Depth | 151 in |
