Volvo
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Operating Weight | 38,978 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 64.2 gal/min |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Hydraulic System Relief Valve Pressure | 5,221 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 6.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic Pump Type | high-flow electronically-controlled |
| Tire Size | 10.00-20 |
| Oscillating Axle Angle | 9 ° |
| Front Diff Fluid Capacity | 2.6 gal |
| Rear Diff Fluid Capacity | 3.4 gal |
Engine
| Engine Model | D6E EDE3 |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 154.0 hp |
| Net Power | 142.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,350 rpm |
| Net Torque | 538 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 85 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 157 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | powershift |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 36,583 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 203 in |
|---|---|
| Max Cutting Height | 349 in |
| Max Reach Along Ground | 331 in |
| Max Loading Height | 235 in |
| Shipping Length of Unit | 323 in |
| Shipping Height of Unit | 118 in |
| Max Vertical Wall Dig Depth | 168 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Reach Along Ground | 348 in |
| Max Loading Height | 245 in |
| Shipping Height of Unit | 126 in |
| Shipping Length of Unit | 323 in |
| Max Vertical Wall Dig Depth | 186 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 227 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 354 in |
| Max Loading Height | 246 in |
| Shipping Height of Unit | 130 in |
| Shipping Length of Unit | 323 in |
| Max Vertical Wall Dig Depth | 191 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 246 in |
|---|---|
| Max Cutting Height | 373 in |
| Max Reach Along Ground | 373 in |
| Max Loading Height | 259 in |
| Shipping Height of Unit | 144 in |
| Shipping Length of Unit | 313 in |
| Max Vertical Wall Dig Depth | 210 in |
