Volvo
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
60 data points
Operating Specifications
| Operating Weight | 48,520 lb |
|---|---|
| Fuel Capacity | 92.5 gal |
| Hydraulic Pump Flow Capacity | 106.0 gal/min |
| Hydraulic System Fluid Capacity | 87.2 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | D6E EAE3 |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 165.0 hp |
| Net Power | 147.0 hp |
| Aspiration | Turbocharged with Intercooler |
| Torque Measured @ | 1,350 rpm |
| Max Torque | 542 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 145 in |
| Tail Swing Radius | 110 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 41,230 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 250 in |
|---|---|
| Max Reach Along Ground | 369 in |
| Max Loading Height | 253 in |
| Max Vertical Wall Digging Depth | 219 in |
| Max Cutting Height | 364 in |
| Shipping Length of Unit | 383 in |
| Shipping Height of Unit | 124 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 265 in |
|---|---|
| Max Vertical Wall Digging Depth | 230 in |
| Max Cutting Height | 373 in |
| Max Loading Height | 263 in |
| Max Reach Along Ground | 384 in |
| Shipping Length of Unit | 380 in |
| Shipping Height of Unit | 119 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 289 in |
|---|---|
| Max Cutting Height | 373 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 244 in |
| Max Reach Along Ground | 403 in |
| Shipping Length of Unit | 380 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 478 in |
|---|---|
| Max Cutting Height | 524 in |
| Max Reach Along Ground | 619 in |
| Max Loading Height | 432 in |
| Max Vertical Wall Dig Depth | 441 in |
| Shipping Length of Unit | 505 in |
