HitachiHitachi
ZX180LCN-3
Excavator
53 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 66,139 lb |
|---|---|
| Fuel Capacity | 134.8 gal |
| Hydraulic Pump Flow Capacity | 144.3 gal/min |
| Hydraulic System Fluid Capacity | 81.9 gal |
| Engine Oil Capacity | 9.3 gal |
| Cooling System Fluid Capacity | 8.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 4.5 gal |
Engine
| Engine Model | 6SDITPD |
|---|---|
| Displacement | 601 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 217.3 hp |
| Net Power | 207.9 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 615 lb-ft |
| Engine Make | Isuzu |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 192 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Reach Along Ground | 430 in |
| Max Loading Height | 281 in |
| Max Vertical Wall Digging Depth | 256 in |
| Max Cutting Height | 403 in |
| Shipping Length of Unit | 431 in |
| Shipping Height of Unit | 126 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
