John Deere
690D
- Operating Weight
- 39,730 lb
- Max Digging Depth
- 234 in
- Max Digging Depth
- 263 in
- Net Power
- 125.0 hp
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 39,730 lb |
|---|---|
| Fuel Capacity | 70.0 gal |
| Hydraulic Pump Flow Capacity | 50.0 gal/min |
| Hydraulic System Fluid Capacity | 96.0 gal |
| Hydraulic System Relief Valve Pressure | 4,060 psi |
| Engine Oil Capacity | 20.0 gal |
| Cooling System Fluid Capacity | 21.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 6.0 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 6414T |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 132.0 hp |
| Net Power | 125.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 420 lb-ft |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 120 in |
| Tail Swing Radius | 108 in |
| Width to Outside of Tracks | 90 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 72 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.4 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 47 |
| Drawbar Pull | 36,000 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 234 in |
|---|---|
| Max Reach Along Ground | 360 in |
| Max Loading Height | 244 in |
| Max Vertical Wall Digging Depth | 191 in |
| Max Cutting Height | 357 in |
| Shipping Length of Unit | 379 in |
| Shipping Height of Unit | 115 in |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.40 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 263 in |
|---|---|
| Max Vertical Wall Digging Depth | 205 in |
| Max Cutting Height | 383 in |
| Max Loading Height | 258 in |
| Max Reach Along Ground | 388 in |
| Shipping Length of Unit | 374 in |
| Shipping Height of Unit | 115 in |
