Hitachi
JCB
427 HT
Wheel Loader
53 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 49,119 lb |
|---|---|
| Fuel Capacity | 101.0 gal |
| Tire Size | 26.5-25-16PR (L3) |
| Hydraulic System Fluid Capacity | 33.9 gal |
| Static Tipping Weight | 38,801 lb |
| Operating Voltage | 24 V |
| Turning Radius | 233 in |
| Engine Oil Fluid Capacity | 10.4 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 12.7 gal |
| Rear Axle/Diff Fluid Capacity | 12.7 gal |
| Cooling System Fluid Capacity | 15.6 gal |
| Transmission Fluid Capacity | 6.7 gal |
Engine
| Engine Model | OM460LA |
|---|---|
| Displacement | 782 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 295.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger & intercooled |
Hydraulic System
| Raise Time | 5.8 s |
|---|---|
| Lower Time | 3.0 s |
| Dump Time | 1.4 s |
| Pump Type | variable displacement axial plunger pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 137 in |
| Wheelbase | 137 in |
| Width Over Tires | 119 in |
| Reach at Max Lift and Dump | 52 in |
| Length with Bucket on Ground | 353 in |
| Hinge Pin - Max Height | 174 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.5 mph |
| Transmission Type | Torque converter countershaft type powershift with computer-controlled automatic shift and manual shit features included |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.21 yd³ |
|---|---|
| Bucket Capacity - struck | 4.39 yd³ |
| Dump Clearance at Max Raise | 119 in |
| Breakout Force | 47,884 lb |
| Bucket Width | 125 in |
