Hitachi
Liebherr
L524 2plus1
Wheel Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 38,030 lb |
|---|---|
| Fuel Capacity | 75.3 gal |
| Tire Size | 23.5-25-16PR (L3) |
| Hydraulic System Fluid Capacity | 30.2 gal |
| Static Tipping Weight | 30,865 lb |
| Operating Voltage | 24 V |
| Turning Radius | 222 in |
| Engine Oil Fluid Capacity | 6.7 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 8.5 gal |
| Rear Axle/Diff Fluid Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 6.7 gal |
Engine
| Engine Model | AH-6HK1X |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 220.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger & Intercooled |
Hydraulic System
| Raise Time | 5.6 s |
|---|---|
| Lower Time | 3.5 s |
| Dump Time | 1.4 s |
| Pump Type | variable displacement axial plunger pump |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 131 in |
| Width Over Tires | 110 in |
| Reach at Max Lift and Dump | 48 in |
| Length with Bucket on Ground | 329 in |
| Hinge Pin - Max Height | 162 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.5 mph |
| Transmission Type | Torque converter countershaft type powershift with computer controlled automatic shift and manual shift features included |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.09 yd³ |
|---|---|
| Bucket Capacity - struck | 3.51 yd³ |
| Dump Clearance at Max Raise | 111 in |
| Breakout Force | 37,993 lb |
| Bucket Width | 115 in |
