Hitachi
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Hydraulic Pump Flow Capacity | 61.9 gal/min |
|---|---|
| Hydraulic System Relief Valve Pressure | 5,076 psi |
Engine
| Engine Model | AJ-4JJ1X |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 1,800 rpm |
| Make | Isuzu |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 57 in |
| Width to Outside of Tracks | 98 in |
Undercarriage
| Max Travel Speed | 3.5 mph |
|---|---|
| Shoe Size | 20 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 325 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 198 in |
| Shipping Length of Unit | 291 in |
| Shipping Height of Unit | 108 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|
