HitachiHitachi
EX135USR
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 27,300 lb |
|---|---|
| Fuel Capacity | 132.5 gal |
| Hydraulic Pump Flow Capacity | 34.0 gal/min |
| Hydraulic System Fluid Capacity | 76.8 gal |
| Engine Oil Capacity | 6.0 gal |
| Cooling System Fluid Capacity | 98.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.0 gal |
| Alternator Supplied Amperage | 88 A |
Engine
| Engine Model | AH-4HK1X |
|---|---|
| Displacement | 317 in³ |
| Net Power | 188.0 hp |
| Aspiration | Turbocharged intercooled |
| Max Torque | 69 lb-ft |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 55,303 lb |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
