Hitachi
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 148.0 gal |
|---|---|
| Hydraulic Fluid Capacity | 40.7 gal |
Engine
| Displacement | 475 in³ |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 247.0 hp |
| Emissions level | Tier 2 |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 132 in |
| Digging Depth | 276 in |
| Digging Reach | 276 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Shoe Size | 30 in |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 287 in |
|---|---|
| Max Reach Along Ground | 430 in |
| Max.Dumping Height | 285 in |
| Max Digging Height | 408 in |
