Hitachi
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Hydraulic Pump Flow Capacity | 41.9 gal/min |
|---|---|
| Hydraulic System Relief Valve Pressure | 3,844 psi |
Engine
| Engine Model | AU-4LE2X |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 4 |
| Make | Isuzu |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 93 in |
Undercarriage
| Max Travel Speed | 3.2 mph |
|---|---|
| Shoe Size | 18 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 157 in |
|---|---|
| Max Reach Along Ground | 278 in |
| Max Loading Height | 269 in |
| Max Vertical Wall Digging Depth | 137 in |
| Shipping Length of Unit | 261 in |
| Shipping Height of Unit | 107 in |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|
