Hyster
Komatsu
FB15M-3
Forklift
22 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 5,130 lb |
|---|---|
| Max Speed | 11.5 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 2,734 lb |
| Front Tire Size | 18 x 6 x 12.1 |
| Rear Tire Size | 14 x 4.5 x 8 |
| Axle load - front | 3,460 lb |
| Axle load - rear | 4,163 lb |
Engine
| Engine Model | E30XN |
|---|---|
| Engine Make | Hyster |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 49 in |
| Overall Width | 39 in |
| Turning Radius | 65 in |
| Overall Height - mast lowered | 83 in |
| Length to Fork Face | 77 in |
| Gradeability | 23.7 % |
| Height to Top of Overhead Guard | 89 in |
| Right Angle Stack | 127 in |
| Rear Tread Range | 32 in |
| Front Tread Range | 31 in |
Mast
| Load Capacity | 3,001 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.4 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.1 mph |
| Max Fork Spread | 82 in |
