Hyundai
HL770XTD-7
- Operating Weight
- 51,919 lb
- Bucket Capacity - heaped
- 5.30 yd³
- Gross Power
- 280.0 hp
- Net Power
- 266.0 hp
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 51,919 lb |
|---|---|
| Fuel Capacity | 113.6 gal |
| Tire Size | 26.5-25 20PR L3 |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Static Tipping Weight | 34,130 lb |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 5.3 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 70 A |
| Front Axle/Diff Fluid Capacity | 20.7 gal |
| Rear Axle/Diff Fluid Capacity | 14.1 gal |
| Cooling System Fluid Capacity | 14.8 gal |
| Transmission Fluid Capacity | 13.8 gal |
Engine
| Engine Model | QSC8.3-C |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 280.0 hp |
| Net Power | 266.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 108.6 gal/min |
|---|---|
| Raise Time | 5.7 s |
| Lower Time | 2.8 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 2,990 psi |
| Pump Type | open-centered tandem circuit system |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 141 in |
| Wheelbase | 135 in |
| Width Over Tires | 118 in |
| Reach at Max Lift and Dump | 50 in |
| Length with Bucket on Ground | 359 in |
| Hinge Pin - Max Height | 189 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 16.4 mph |
| Transmission Type | fully automatic power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 5.30 yd³ |
|---|---|
| Bucket Capacity - struck | 4.60 yd³ |
| Dump Clearance at Max Raise | 142 in |
| Breakout Force | 45,040 lb |
| Bucket Width | 122 in |
