Hyundai
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 5,787 lb |
|---|---|
| Max Speed | 7.3 mph |
| Fuel Capacity | 16.0 gal |
| Hydraulic System Fluid Capacity | 10.0 gal |
| Tire Size | 10-16.5 6PR |
Engine
| Engine Model | V2203M |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 18.4 gal/min |
|---|---|
| Relief Valve Pressure | 2,538 psi |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 40 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 22 in |
| Length with Bucket | 130 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - inc bucket | 76 in |
| Turning Radius from Center - machine rear | 62 in |
| Length w/o Bucket | 104 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,433 lb |
| Tipping Angle | 2,538 ° |
