Hyundai
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 5,571 lb |
|---|---|
| Max Speed | 6.1 mph |
| Fuel Capacity | 17.0 gal |
| Hydraulic System Fluid Capacity | 8.1 gal |
| Tire Size | 10.00x16.5 |
Engine
| Engine Model | V2203T |
|---|---|
| Power Measured @ | 2,800 rpm |
Hydraulic System
| Pump Flow Capacity | 16.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,400 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 74 in |
| Wheelbase | 36 in |
| Width Over Tires | 57 in |
| Reach at Max Lift and Dump | 28 in |
| Length with Bucket | 128 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 73 in |
| Turning Radius from Center - machine rear | 62 in |
| Length w/o Bucket | 106 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,500 lb |
| Tipping Angle | 2,998 ° |
