Hyundai
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 7,187 lb |
|---|---|
| Max Speed | 7.3 mph |
| Fuel Capacity | 21.7 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
| Tire Size | 12X16.5 |
Engine
| Engine Model | 4TNE98 |
|---|---|
| Power Measured @ | 2,500 rpm |
Hydraulic System
| Pump Flow Capacity | 19.7 gal/min |
|---|---|
| Relief Valve Pressure | 2,465 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 79 in |
| Wheelbase | 42 in |
| Width Over Tires | 69 in |
| Reach at Max Lift and Dump | 22 in |
| Length with Bucket | 137 in |
| Clearance at Max Lift and Dump | 101 in |
| Turning Radius from Center - inc bucket | 78 in |
| Turning Radius from Center - machine rear | 66 in |
| Length w/o Bucket | 111 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Tipping Angle | 3,598 ° |
