Hyundai
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 7,253 lb |
|---|---|
| Max Speed | 7.2 mph |
| Fuel Capacity | 22.0 gal |
| Hydraulic System Fluid Capacity | 15.0 gal |
| Tire Size | 12-16.5 12PR |
Engine
| Engine Model | V3300DI |
|---|---|
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 17.7 gal/min |
|---|---|
| Relief Valve Pressure | 2,538 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 79 in |
| Wheelbase | 44 in |
| Width Over Tires | 73 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 137 in |
| Clearance at Max Lift and Dump | 96 in |
| Turning Radius from Center - inc bucket | 82 in |
| Turning Radius from Center - machine rear | 65 in |
| Length w/o Bucket | 113 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,852 lb |
| Tipping Angle | 3,715 ° |
