Hyundai

HSL960T

Skid Steer Loader

Operating Weight
7,200 lb
All skid steer loaders
Hyundai HSL960T Skid Steer Loader
1 / 5
Image 1 of 5
Image: lectura.press

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight7,200 lb
Fuel Capacity21.2 gal
Hydraulic System Fluid Capacity17.5 gal
Tire Size12x16.5
Operating Speed7.8 mph

Engine

Engine specifications
Engine ModelV2003MT
Power Measured @2,800 rpm

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity20.0 gal/min
Relief Valve Pressure3,000 psi

Dimensions

Dimensions specifications
Ground Clearance9 in
Height - Top of Cab84 in
Wheelbase43 in
Width Over Tires69 in
Reach at Max Lift and Dump31 in
Length with Bucket141 in
Clearance at Max Lift and Dump96 in
Turning Radius from Center - inc bucket84 in
Turning Radius from Center - machine rear68 in
Length w/o Bucket113 in

Loader

Loader specifications
Operating Load Rating2,101 lb
Tipping Angle4,251 °
