Hyundai
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Fuel Capacity | 105.7 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 117.3 gal/min |
| Hydraulic System Fluid Capacity | 75.3 gal |
| Hydraulic System Relief Valve Pressure | 4,978 psi |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 9.3 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | QSB6.7 |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 195.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 687 lb-ft |
| Make | Cummins |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 151 in |
| Tail Swing Radius | 118 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Loading Height | 251 in |
|---|---|
| Max Vertical Wall Digging Depth | 216 in |
| Max Cutting Height | 373 in |
| Shipping Length of Unit | 396 in |
| Shipping Height of Unit | 139 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.00 yd³ |
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 254 in |
|---|---|
| Max Vertical Wall Digging Depth | 223 in |
| Max Cutting Height | 373 in |
| Max Loading Height | 253 in |
| Max Reach Along Ground | 381 in |
| Shipping Length of Unit | 395 in |
| Shipping Height of Unit | 142 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 276 in |
|---|---|
| Max Cutting Height | 381 in |
| Max Loading Height | 261 in |
| Max Vertical Wall Digging Depth | 243 in |
| Max Reach Along Ground | 402 in |
| Shipping Length of Unit | 391 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 298 in |
|---|---|
| Max Cutting Height | 391 in |
| Max Reach Along Ground | 422 in |
| Max Loading Height | 271 in |
| Max Vertical Wall Dig Depth | 270 in |
| Shipping Length of Unit | 391 in |
