Hyundai

ROBEX 360LC-7

Excavator

Max Digging Depth
269 in
Max Digging Depth
296 in
Net Power
261.0 hp
All excavators
Hyundai ROBEX 360LC-7 Excavator
1 / 5
Image 1 of 5
Image: bossmachinery.nl

Specifications

70 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity137.4 gal
Hydraulic Pump Flow Capacity153.3 gal/min
Hydraulic System Fluid Capacity100.4 gal
Hydraulic System Relief Valve Pressure4,690 psi
Engine Oil Capacity7.1 gal
Cooling System Fluid Capacity11.9 gal
Operating Voltage24 V
Swing Drive Fluid Capacity2.2 gal
Alternator Supplied Amperage50 A

Engine

Engine specifications
Engine ModelQSC8.3C
Displacement506 in³
Power Measured @1,900 rpm
Gross Power280.0 hp
Net Power261.0 hp
Aspirationturbocharged
Torque Measured @1,400 rpm
Max Torque870 lb-ft

Dimensions

Dimensions specifications
Ground Clearance23 in
Height - Top of Cab126 in
Length of Track on Ground172 in
Tail Swing Radius135 in
Width to Outside of Tracks132 in
Removal Counterweight Clearance52 in
Digging Depth288 in
Digging Reach288 in

Undercarriage

Undercarriage specifications
Ground Pressure9 psi
Track Gauge108 in
Number of Track Rollers per Side9
Max Travel Speed2.8 mph
Shoe Size24 in
Number of Shoes per Side51
Number of Carrier Rollers per Side2
Drawbar Pull68,350 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth269 in
Max Reach Along Ground414 in
Max Loading Height287 in
Max Vertical Wall Digging Depth234 in
Max Cutting Height413 in
Shipping Length of Unit443 in
Shipping Height of Unit146 in

Bucket

Bucket specifications
Reference Bucket Capacity2.20 yd³
Maximum Bucket Capacity3.10 yd³
Minimum Bucket Capacity1.60 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth296 in
Max Vertical Wall Digging Depth251 in
Max Cutting Height411 in
Max Loading Height288 in
Max Reach Along Ground433 in
Shipping Length of Unit438 in
Shipping Height of Unit135 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth324 in
Max Cutting Height420 in
Max Loading Height296 in
Max Vertical Wall Digging Depth277 in
Max Reach Along Ground459 in
Shipping Length of Unit437 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth340 in
Max Cutting Height442 in
Max Reach Along Ground480 in
Max Loading Height317 in
Max Vertical Wall Dig Depth298 in
Shipping Length of Unit435 in

Boom/Stick Excavator Option 5

Boom/Stick Excavator Option 5 specifications
Max Digging Depth254 in
Max Reach Along Ground398 in
Max Cutting Height402 in
Max Loading Height277 in
Max Vertical Wall Dig Depth217 in
Shipping Height of Unit151 in
Shipping Length of Unit428 in
