Hyundai
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
72 data points
Operating Specifications
| Fuel Capacity | 145.3 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 575.9 gal/min |
| Hydraulic System Fluid Capacity | 108.4 gal |
| Hydraulic System Relief Valve Pressure | 4,765 psi |
| Engine Oil Capacity | 8.9 gal |
| Cooling System Fluid Capacity | 11.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2.2 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | QSL |
|---|---|
| Displacement | 540 in³ |
| Power Measured @ | 1,850 rpm |
| Gross Power | 296.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,070 lb-ft |
| Make | Cummins |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 172 in |
| Tail Swing Radius | 135 in |
| Width to Outside of Tracks | 135 in |
| Removal Counterweight Clearance | 52 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 108 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Loading Height | 291 in |
|---|---|
| Max Vertical Wall Digging Depth | 234 in |
| Max Cutting Height | 418 in |
| Shipping Length of Unit | 443 in |
| Shipping Height of Unit | 146 in |
Bucket
| Reference Bucket Capacity | 2.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.80 yd³ |
| Minimum Bucket Capacity | 2.00 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 296 in |
|---|---|
| Max Vertical Wall Digging Depth | 250 in |
| Max Cutting Height | 417 in |
| Max Loading Height | 293 in |
| Max Reach Along Ground | 435 in |
| Shipping Length of Unit | 438 in |
| Shipping Height of Unit | 137 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 324 in |
|---|---|
| Max Cutting Height | 426 in |
| Max Loading Height | 301 in |
| Max Vertical Wall Digging Depth | 277 in |
| Max Reach Along Ground | 459 in |
| Shipping Length of Unit | 441 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 340 in |
|---|---|
| Max Cutting Height | 448 in |
| Max Reach Along Ground | 480 in |
| Max Loading Height | 322 in |
| Max Vertical Wall Dig Depth | 298 in |
| Shipping Length of Unit | 438 in |
Boom/Stick Excavator Option 5
| Max Digging Depth | 254 in |
|---|---|
| Max Reach Along Ground | 398 in |
| Max Cutting Height | 407 in |
| Max Loading Height | 281 in |
| Max Vertical Wall Dig Depth | 217 in |
| Shipping Height of Unit | 149 in |
| Shipping Length of Unit | 428 in |
Boom/Stick Excavator Option 6
| Max Digging Depth | 443 in |
|---|---|
| Max Reach Along Ground | 596 in |
| Max Cutting Height | 526 in |
| Max Loading Height | 401 in |
| Max Vertical Wall Dig Depth | 397 in |
| Shipping Length of Unit | 515 in |
| Shipping Height of Unit | 194 in |
