Hyundai
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Fuel Capacity | 248.4 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 266.3 gal/min |
| Hydraulic System Fluid Capacity | 211.4 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 11.5 gal |
| Cooling System Fluid Capacity | 15.6 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | QSX15 |
|---|---|
| Displacement | 915 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 510.0 hp |
| Net Power | 490.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,744 lb-ft |
| Make | Cummins |
Dimensions
| Ground Clearance | 35 in |
|---|---|
| Height - Top of Cab | 142 in |
| Length of Track on Ground | 199 in |
| Tail Swing Radius | 170 in |
| Width to Outside of Tracks | 174 in |
| Removal Counterweight Clearance | 62 in |
Undercarriage
| Ground Pressure | 15 psi |
|---|---|
| Track Gauge | 138 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 285 in |
|---|---|
| Max Loading Height | 296 in |
| Max Vertical Wall Digging Depth | 224 in |
| Max Cutting Height | 463 in |
| Shipping Length of Unit | 516 in |
| Shipping Height of Unit | 199 in |
Bucket
| Reference Bucket Capacity | 6.00 yd³ |
|---|---|
| Maximum Bucket Capacity | 6.70 yd³ |
| Minimum Bucket Capacity | 4.50 yd³ |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 333 in |
|---|---|
| Max Vertical Wall Digging Depth | 245 in |
| Max Cutting Height | 466 in |
| Max Loading Height | 305 in |
| Max Reach Along Ground | 519 in |
| Shipping Length of Unit | 550 in |
| Shipping Height of Unit | 211 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 346 in |
|---|---|
| Max Cutting Height | 465 in |
| Max Loading Height | 306 in |
| Max Vertical Wall Digging Depth | 244 in |
| Max Reach Along Ground | 529 in |
| Shipping Length of Unit | 556 in |
| Shipping Height of Unit | 207 in |
