Ingersoll Rand
Dynapac
CG233HF
Smooth Drum Roller
19 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 17,780 lb |
|---|---|
| Max Speed | 9.6 mph |
| Fuel Capacity | 47.1 gal |
| Operating Width | 74 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 22.2 gal |
| Alternator Supplied Amperage | 105 A |
Engine
| Engine Model | B4.5T Tier2 |
|---|---|
| Net Power | 99.0 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Height - Top of Cab | 117 in |
|---|---|
| Wheelbase | 9 in |
| Width Over Tires | 74 in |
| Turning Radius - Inside | 128 in |
| Overall Length w/o Blade | 199 in |
Tires & Wheels
| Tires | 14.9x24 -6PR R1 |
|---|
Drum
| Drum Width | 66 in |
|---|---|
| Drum Diameter | 48 in |
| Vibration Frequency 1 | 20 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 29,900 lb |
| Vibration Frequency | 1,850 – 2,025 vpm |
| Centrifugal Force - Low | 29,900 lb |
| Nominal Amplitude - Low | 0 in |
| Pad Height | 3 in |
| Pad Surface Area | 21 in³ |
| Number of Pads | 84 |
| Vibratory Frequency 2 | 34 vpm |
