Dynapac

CG233HF

Smooth Drum Roller

Operating Weight
19,621 lb
Max Speed
7.5 mph
Drum Width
57 in
Gross Power
84.0 hp
All smooth drum rollers
Dynapac CG233HF Smooth Drum Roller
1 / 5
Image 1 of 5
Image: dynapac.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight19,621 lb
Max Speed7.5 mph
Fuel Capacity26.5 gal

Engine

Engine specifications
Engine ModelBF4M 2011
Gross Power84.0 hp
Aspirationair cooled diesel

Dimensions

Dimensions specifications
Ground Clearance11 in
Height - Top of Cab117 in
Wheelbase9 in
Overall Length13 in
Overall Width62 in

Drum

Drum specifications
Drum Width57 in
Drum Diameter44 in
Vibration Frequency 154 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High20,008 lb
Vibration Frequency 267 vpm
Centrifugal Force - Low15,287 lb
Nominal Amplitude - Low0 in
