Ingersoll Rand
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 26,460 lb |
|---|---|
| Fuel Capacity | 67.9 gal |
| Operating Width | 90 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 22.2 gal |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | QSB5.9-30T |
|---|---|
| Gross Power | 156.0 hp |
| Make | Cummins |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 10 in |
| Overall Length | 19 in |
| Overall Width | 12 in |
| Turning Radius - Inside | 136 in |
Tires & Wheels
| Tires | 23.1x26-18PR R3 |
|---|
Drum
| Drum Diameter | 59 in |
|---|---|
| Vibration Frequency 1 | 31 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 63,171 lb |
| Vibration Frequency 2 | 34 vpm |
| Vibration Frequency | 1,225 – 2,025 vpm |
| Centrifugal Force - Low | 46,311 lb |
| Nominal Amplitude - Low | 0 in |
