BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 24,912 lb |
|---|---|
| Max Speed | 6.6 mph |
| Fuel Capacity | 79.3 gal |
| Operating Width | 89 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Engine Oil Capacity | 2.9 gal |
| Alternator Supplied Amperage | 95 A |
| Cooling System Fluid Capacity | 3.7 gal |
Engine
| Engine Model | B 3.9-125 C |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 124.8 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 117 in |
| Wheelbase | 9 in |
| Overall Length | 18 in |
| Turning Radius - Inside | 134 in |
Tires & Wheels
| Tires | 23.1-26/8PR AWT |
|---|
Drum
| Drum Width | 83 in |
|---|---|
| Drum Diameter | 59 in |
| Vibration Frequency 1 | 31 vpm |
| Vibration Frequency 2 | 36 vpm |
| Static Linear Load | 13 lb-ft |
| Vibration Frequency | — |
| Nominal Amplitude - Med | 0 in |
