PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 8,003 lb |
|---|---|
| Max Speed - high range | 6.9 mph |
| Fuel Capacity | 21.2 gal |
| Hydraulic System Fluid Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Engine Oil Capacity | 2.6 gal |
Engine
| Engine Model | 404C-22T |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 60.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,800 rpm |
| Peak Torque | 140 lb-ft |
Hydraulic System
| Pump Flow | 15.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | hydrostatic drive pumps |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 77 in |
| Reach at Max Lift and Dump | 22 in |
| Width Over Tracks | 66 in |
| Length with Bucket | 132 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - inc bucket | 81 in |
| Turning Radius from Center - machine rear | 62 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Length of Track on Ground | 56 in |
| Width of Track | 13 in |
| Ground Contact Area | 1,395 in³ |
| Track Gauge | 54 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Tipping Angle | 5,166 ° |
| Operating Load | 1,808 lb |
| Breakout Force | — |
