JCB
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
20 data points
Engine
| Engine Model | JCB EcoMAX Tier 4 Final / IV |
|---|---|
| Displacement | 293 in³ |
| Net Power | 173.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 509 lb-ft |
| Engine Make | JCB |
| Stroke | 5 in |
| Bore | 4 in |
| Engine Type | 4 stroke 4 cylinder in-line direct injection turbocharged diesel |
| Alternator | 100 A |
| Battery | 2 x 12 volt. |
| Air filter type | Dry element with in cab warning indicator |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 120 in |
| Overall Height | 126 in |
| Track Gauge | 86 in |
| Counterweight Clearance | 43 in |
| Undercarriage Overall Length | 165 in |
| Track height | 35 in |
Boom/Stick Excavator Option 3
| Overall height | 126 in |
|---|
