JCB
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 9,288 lb |
|---|---|
| Max Speed | 12.4 mph |
| Fuel Capacity | 27.3 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
| Tire Size | 12 x 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
| Engine Oil Fluid Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 4.1 gal |
| Chain Box Fluid Capacity - each side | 6.1 gal |
| Operating Speed | 6.8 mph |
Engine
| Engine Model | EcoMAX TCAE-55 |
|---|---|
| Displacement | 268 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 74.0 hp |
| Aspiration | Turbo |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 295 lb-ft |
| Emissions Certification | EPA-T4F (EU St3B) |
| Cooling system | Liquid |
| Battery | 12 V |
| Fuel | Diesel |
| Engine oil service interval | 500 h |
Hydraulic System
| Pump Flow Capacity | 23.8 gal/min |
|---|---|
| Relief Valve Pressure | 3,335 psi |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 50 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket | 150 in |
| Clearance at Max Lift and Dump | 97 in |
| Turning Radius from Center - inc bucket | 87 in |
| Turning Radius from Center - machine rear | 69 in |
| Dump Height | 91 in |
| Dump angle | 42 ° |
| Angle of departure | 29 ° |
| Loadover height | 114,174 in |
| Dig Depth | 394 in |
| Pin height | 125,984 in |
| Rollback - Ground Level | 30 ° |
Transmission
| Travel Speed | 12.5 mph |
|---|
Tires & Wheels
| Standard | 12 x 16.5 - 10 PR Xtra Wall Off Road |
|---|
General Specifications
| Engine Power HP (KW) | 74 (55) — Starting 2019 Model Year |
|---|---|
| Operating Width IN. (CM) | 75 (190) — Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 3,000 (1,361) — Starting 2016 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 3,186 (1,445) — Starting 2019 Model Year |
| Rated Operating Capacity LBS. (KG) | 3,186 (1,445) — Starting 2025 Model Year |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 3,000 lb |
| Tipping Angle | 6,369 ° |
| Operating Width | 72 in |
| Breakout Force | — |
| Bucket Width | 75 in |
| Loader lift capacity with bucket | 6,056 lb |
