JCB
Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 5,527 lb |
|---|---|
| Fuel Capacity | 12.7 gal |
| Hydraulic System Fluid Capacity | 10.6 gal |
| Engine Oil Fluid Capacity | 1.8 gal |
| Cooling System Fluid Capacity | 1.8 gal |
Engine
| Engine Model | V1505 |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 36.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 2,200 rpm |
| Engine Make | Kubota |
| Air cleaner | Donaldson FPG057502 |
| Emissions level | Stage 3A |
| No. of Valves | 4 |
| Fan drive type | Direct mount |
Hydraulic System
| Pump Flow Capacity | 10.7 gal/min |
|---|---|
| Raise Time | 4.4 s |
| Lower Time | 3.0 s |
| Dump Time | 2.7 s |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 88 in |
| Wheelbase | 64 in |
| Width Over Tires | 56 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket on Ground | 173 in |
| Hinge Pin - Max Height | 114 in |
Transmission
| Max Speed - Forward | 18.7 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Transmission Type | ZF / Bosch-Rexroth |
Bucket
| Dump Clearance at Max Raise | 79 in |
|---|---|
| Breakout Force | 2,833 lb |
Electrical System
| Voltage | 12 V |
|---|---|
| Alternator | — |
| Battery capacity | 72 Ah |
Axles
| Axle oil front | 0.9 gal |
|---|---|
| Axle oil rear | 1.1 gal |
