Wacker Neuson
TCM
L3-2
Wheel Loader
16 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 4,057 lb |
|---|---|
| Fuel Capacity | 5.6 gal |
| Tire Size | 27x10.5-15 EM (earthmoving) |
| Hydraulic System Fluid Capacity | 4.8 gal |
| Static Tipping Weight | 2,017 lb |
| Turning Radius | 101 in |
| Rear Axle Oscillation | 24 ° |
Engine
| Engine Model | 403C-11 |
|---|---|
| Gross Power | 24.8 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.7 gal/min |
|---|---|
| Relief Valve Setting | 2,828 psi |
| Pump Type | gear pump |
Dimensions
| Height - Top of Cab | 73 in |
|---|---|
| Wheelbase | 54 in |
| Width Over Tires | 42 in |
| Length with Bucket on Ground | 137 in |
| Hinge Pin - Max Height | 108 in |
Transmission
| Transmission Type | hydrostatic all-wheel drive with automotive style control |
|---|
Bucket
| Bucket Capacity - heaped | 0.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 81 in |
| Breakout Force | 2,792 lb |
