Schaffer
Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 3,858 lb |
|---|---|
| Fuel Capacity | 6.1 gal |
| Tire Size | 16X12-12 |
| Hydraulic System Fluid Capacity | 8.0 gal |
| Static Tipping Weight | 1,984 lb |
Engine
| Engine Model | D1105 |
|---|---|
| Gross Power | 26.0 hp |
Hydraulic System
| Pump Flow Capacity | 23.8 gal/min |
|---|---|
| Relief Valve Setting | 4,300 psi |
Dimensions
| Height - Top of Cab | 83 in |
|---|---|
| Wheelbase | 55 in |
| Width Over Tires | 50 in |
| Reach at Max Lift and Dump | 24 in |
| Length with Bucket on Ground | 138 in |
| Hinge Pin - Max Height | 100 in |
Transmission
| Max Speed - Forward | 9.4 mph |
|---|---|
| Max Speed - Reverse | 9.4 mph |
Bucket
| Bucket Capacity - heaped | 0.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 76 in |
| Breakout Force | 2,248 lb |
