JCB
Hitachi
LX40-7
Wheel Loader
40 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 13,067 lb |
|---|---|
| Fuel Capacity | 21.2 gal |
| Hydraulic System Fluid Capacity | 18.5 gal |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rated Bucket Capacity | 1.29 yd³ |
Engine
| Engine Model | JCB Diesel by Kohler - KDI 2504 TCR |
|---|---|
| Displacement | 152 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 74.0 hp |
| Net Power | 72.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Make | Duetz |
| Engine Type | 4 stroke Electronic Common Rail |
| Emissions level | Stage 3A Tier 4 Final |
Weights
| Operating Weight | 12,830 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 23.6 gal/min |
|---|---|
| Raise Time | 4.9 s |
| Lower Time | 3.0 s |
| Dump Time | 4.1 s |
| Pump Type | Single Gear Pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 88 in |
| Width Over Tires | 76 in |
| Reach at Max Lift and Dump | 22 in |
| Length with Bucket on Ground | 216 in |
| Hinge Pin - Max Height | 132 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Transmission Type | Hydrostatic |
Bucket
| Bucket Capacity - heaped | 1.40 yd³ |
|---|---|
| Dump Clearance at Max Raise | 103 in |
| Breakout Force | 12,095 lb |
| Bucket Width | 77 in |
General Specifications
| Operating Weight | 13,296 (6,031) — Starting 2019 Model Year |
|---|---|
| Operating Weight lbs (kg) | 13,296 (6,031) — Starting 2025 Model Year |
| Bucket Capacity | 1.3 (1.0) — Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 1.3 (1.0) — Starting 2025 Model Year |
| Engine type | JCB Diesel by Kohler KDI 2504 TCR — Starting 2019 Model Year |
| Engine Power | 74 (55) — Starting 2019 Model Year |
| Max Dump Height | 10.5 (3.2) — Starting 2024 Model Year |
| Max Dump Height ft.( m) | 8' 7" (2616) — Starting 2026 Model Year |
| OperatingWeight lbs. (kg) | 13,065 (5,926) — Starting 2026 Model Year |
| Engine Power Gross hp (kW) | 74 (55) — Starting 2025 Model Year |
Electrical System
| Voltage | 12 V |
|---|---|
| Alternator | — |
| Battery capacity | 100 Ah |
Axles
| Axle oil front | 1.2 gal |
|---|---|
| Axle oil rear | 1.6 gal |
