Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Fuel Capacity | 85.9 gal |
|---|---|
| Tire Size | 23.5X25X12 PLY (L2) |
| Hydraulic System Fluid Capacity | 56.8 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 5.0 gal |
| Rear Axle Oscillation | 25 ° |
| Alternator Supplied Amperage | 55 A |
| Front Axle/Diff Fluid Capacity | 13.5 gal |
| Rear Axle/Diff Fluid Capacity | 13.5 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 7.4 gal |
Engine
| Engine Model | 6CT8.33-C |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 205.0 hp |
| Net Power | 190.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
Hydraulic System
| Pump Flow Capacity | 87.0 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 3.5 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 2,774 psi |
| Pump Type | variable displacement load sensing pumps |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 126 in |
| Width Over Tires | 107 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 305 in |
| Hinge Pin - Max Height | 162 in |
Transmission
| Max Speed - Forward | 23.3 mph |
|---|---|
| Max Speed - Reverse | 15.2 mph |
| Transmission Type | full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.70 yd³ |
|---|---|
| Bucket Capacity - struck | 3.30 yd³ |
| Dump Clearance at Max Raise | 120 in |
| Breakout Force | 45,620 lb |
| Bucket Width | 110 in |
