JCB
John Deere
120C
Excavator
51 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 47,785 lb |
|---|---|
| Fuel Capacity | 90.7 gal |
| Hydraulic Pump Flow Capacity | 113.1 gal/min |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 5.7 gal |
| Cooling System Fluid Capacity | 6.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | Tierr II |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 138.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 145 in |
| Tail Swing Radius | 111 in |
| Width to Outside of Tracks | 109 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 86 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 343 in |
| Max Loading Height | 250 in |
| Max Vertical Wall Digging Depth | 193 in |
| Max Cutting Height | 353 in |
| Shipping Length of Unit | 377 in |
| Shipping Height of Unit | 121 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 120 in |
|---|---|
| Max Vertical Wall Digging Depth | 216 in |
| Max Cutting Height | 362 in |
| Max Loading Height | 258 in |
| Max Reach Along Ground | 361 in |
| Shipping Length of Unit | 377 in |
| Shipping Height of Unit | 121 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 260 in |
|---|---|
| Max Cutting Height | 371 in |
| Max Loading Height | 267 in |
| Max Vertical Wall Digging Depth | 240 in |
| Max Reach Along Ground | 383 in |
| Shipping Length of Unit | 372 in |
| Shipping Height of Unit | 120 in |
