JCB
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Hydraulic Pump Flow Capacity | 77.7 gal/min |
|---|---|
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | BB-6BGIT |
|---|---|
| Displacement | 396 in³ |
| Net Power | 138.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 145 in |
| Tail Swing Radius | 114 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 42 in |
| Digging Depth | 252 in |
| Digging Reach | 252 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Shoe Size | 24 in |
