JCB
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 31.8 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 45.0 gal/min |
| Hydraulic System Fluid Capacity | 24.4 gal |
| Hydraulic System Relief Valve Pressure | 4,351 psi |
| Engine Oil Capacity | 2.6 gal |
| Cooling System Fluid Capacity | 2.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | A-4JGI |
|---|---|
| Displacement | 187 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 58.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Digging Depth | 180 in |
|---|---|
| Digging Reach | 180 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 18 in |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 246 in |
| Max Loading Height | 204 in |
| Max Vertical Wall Digging Depth | 138 in |
| Max Cutting Height | 285 in |
Bucket
| Reference Bucket Capacity | 0.30 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 181 in |
|---|---|
| Max Vertical Wall Digging Depth | 159 in |
| Max Cutting Height | 302 in |
| Max Loading Height | 220 in |
| Max Reach Along Ground | 264 in |
